HBM UK Ltd. - PRODUCT NEWS
HBM MAKES ITS STAND AT THE AUTOMOTIVE TESTING SHOW - STAND NO: 134
HBM a market leader in the field of test and measurement technology will be exhibiting its eDrive testing solution for effective analysing of electric machines and drives, together with its data acquisition range, on Stand 134 at this years Automotive Testing Show on the 13th and 14th September.
Taking place at Ricoh Arena in Coventry, The Automotive Testing Show is a complete automotive engineering technical event designed for anyone involved in power train development, vehicle development, simulation, NVH, software engineering, calibration or controls.
For those who are interested in measuring the performance and efficiency of electric motors and invertors, HBM will be exhibiting its revolutionary eDrive Test System, which is a robust and integrated system.
The eDrive testing solution combines HBMs T12 or T40 Torque Senor, the most accurate torque transducers in each respective class; the GEN3i Data Acquisition System; and, as an option, the Quantum 1609B Temperature Satellite, to provide synchronous, dynamic and continuous acquisition of mechanical and electrical signals from an electric drive system. In addition to making temperature, torque and rotational measurements, the eDrive testing solution from HBM can also make measurements from as many as 18 current and voltage channels at voltages up to 1,000 V, at a sampling rate of up to 2 MS/s.
Furthermore, the system incorporates an intuitive eDrive software GUI which has been developed exclusively for electric motor and inverter testing and for noise immunity. In addition to providing raw data, the innovative system from HBM provides real-time results, such as true, reactive and apparent power and efficiency calculations.
HBMs eDrive package is the only completely integrated test solution on the market that allows engineers to record, verify and study both electrical and mechanical parameters under dynamic conditions, comments Mike Hoyer, HBM Applications Engineer.
Visitors to the show are also invited to come and find out more about theSoMat XR rugged and flexible data acquisition system, which has been specifically developed for use in harsh environments, and the QuantumX data acquisition range for reliable data acquisition, both from HBM.
As test engineers require highly precise and repeatable test results, which often need to be acquired in adverse and harsh conditions, testing vehicles can often present a challenge. However, with more and more emphasis being placed on improving performance, the need to utilise a modern data acquisition system which offers a reliable and robust measurement capability, which can be easily adapted to perform a variety of measurement tasks, under a variety of conditions, seems to be the most obvious solution good measurement data is, after all, essential for optimising design.
HBM provide a full range of strain gauges, transducers and data acquisition instrumentation and software which can be used in a wide range of applications in the automotive industry.
Founded in Germany in 1950, HBM is today the technology and market leader in the field of test and measurement. HBM's product range comprises solutions for the entire measurement chain, from virtual to physical testing. The company has production facilities in Germany, USA and China and is represented in over 80 countries worldwide.
For further information please contact:
