New FSL Low-Profile
Force Sensor
New FSL Low-ProfiIe Force Sensor
offers improved specifications.
The new, improved FSL Series Low-Profile Force Sensor
from the Sensing and Control Business of Honeywell is a
cost-effective, instrument-grade, precision force-sensing product.
The sensor combines high accuracy (a typical sensitivity shift over
the specified temperature range of +/- 0.006 mV/gram) with robust
performance characteristics. Miniature packaging provides
application versatility.
Typical applications include medical equipment control (kidney
dialysis machines, drug delivery systems, hematology equipment,
and medical instrumentation); ultra-low displacement sensing in
robotic end-effectors, process control equipment, inspection controls,
and wire bonding equipment; and high-precision force sensing, such as
variable tension control, materials testing, and liquid-level measurement.
The FSL Series force sensor features a proven sensing technology
that utilizes a specialized piezoresistive micro-machined silicon-sensing
element. The low-power, unamplified, non-compensated Wheatstone
bridge circuit design provides inherently stable mV outputs over the
500 gram force range.
Operating temperature range is —40 to +70 degrees C
(-40 to +158 degrees F). The product meets IEC 801-2 testing requirements.
____________________________________________________
For more information, please contact :-
Honeywell Control Systems Ltd.
For more details of this product...
email our HelpDesk quoting Ref. shown below
Ref: Honeywell002
August 2000
