Kistler Instruments Ltd. - PRODUCT NEWS






Achieving 100% quality injection moulding even faster

The new firmware upgrade V2.4 for Kistler's CoMo Injection process monitoring system offers better functionality and new features that will help processors achieve zero-defect production even faster.


The integrated, automatic mould recognition function of the CoMo Injection system makes mould connection and setting easier and faster with automatic loading of mould data during mould changes. Connection errors are detected quickly and can be remedied before they can cause any damage. Kistler has made the synchronized processing of uniform evaluation objects for pressure monitoring of multi-cavity moulds significantly easier. Evaluation objects of the same type can be selected across channels and processed synchronously afterwards.

The MultiFlow, the automatic hot-runner balancing function of the CoMo Injection system, now offers more options. Tip temperatures can now be controlled with higher precision with Smooth Control mode. This enhancement allows injection moulding processes involving polymers with a viscosity that is significantly affected by temperature changes to be controlled more accurately. These improvements will be of particular benefit to operators of multi-cavity moulds for thermoplastic elastomers and other temperature-sensitive polymers. Individual process variations are detected reliably and their effect on process control is eliminated. MultiFlow now also offers an automatic start-up function, which is triggered automatically during production start-up and after production downtimes.

The CoMo Injection system's output channels for controlling reject gates or removal robots are now easily tested via One Touch check. This function ensures the reliable separation of rejects and allows network-based data management for easier data handling.

As an industrial process monitoring system, CoMo Injection is equipped with connectors for multichannel technology as standard. However, in some cases the use of sensory equipment for testing purposes may require a higher level of connective versatility. Fitted with modules of the new Lab Conversion Kit (LabKit), CoMo Injection can now offer more connection versatility which allows the direct connection and exchange of individual sensors as required. Modules for individual charge and voltage signals and modules with integrated amplifiers for thermocouples Type K or J are also available. Easy assembly and disassembly allows operators easy switchover and full use of the benefits of multichannel cable technology or separate connections versatility. The modular design of the CoMo LabKit allows easy adaptation and enhancement as needed.




Kistler Group
Established in Winterthur (Switzerland) in 1957, the Kistler Group now has a worldwide presence with 25 group companies and 30 distributors ensuring prompt, local application support and short delivery times. With a staff of more than 1050, the Kistler Group is one of the world's leading providers of dynamic measuring instrumentation with a turnover of 210 million Swiss Francs (GBP 145M) in the 2010 financial year.
Kistler's core competence is the development, production and use of sensors for measuring pressure, force and acceleration. Kistler's know-how and electronic systems can be used to prepare measuring signals for use in analysing physical processes, controlling and optimising industrial processes, improving product quality in manufacturing and improving performance in sports and rehabilitation.
Kistler offers a comprehensive range of sensors and systems for engine development, automotive engineering, plastics and metal processing, installation technology and biomechanics.
Heavy investment in research and development, 15% of staff worldwide are engaged in research and development, has generated a number of innovations using piezoelectric, piezoresistive and capacitive techniques to provide solutions to numerous force, pressure and acceleration measuring problems. These innovations include the world's first commercial quartz sensor, two-wire constant current technology to integrate sensors with microelectronic circuitry, high-temperature pressure sensors for use up to 400 Deg C and three-component force measuring sensors.

For more information, please contact :-

Kistler Instruments Ltd.
13 Murrell Green Business Park, London Road, Hook RG27 9GR
Tel: +44 (0)1256 741550
Fax: +44 (0)1256 741551
Email:
sales.uk@Kistler.com
Website: http://www.kistler.com

October 2013
