Kistler Instruments Ltd. - PRODUCT NEWS





Kistler at Control 2018

Kistler will be present at Control, the world's leading quality assurance trade fair from 24 to 27 April 2018 in Stuttgart. The Group will be showcasing its portfolio of industrial testing and inspection systems with the spotlight on the very latest additions. Alongside automated testing and sorting systems from Vester, featured application areas will include force and torque sensors as well as fastening technology. Yet another highlight: the world's first digital charge amplifier.

Industrial production has to meet ever-increasing requirements for performance capacity and compliance with standards – so quality assurance is becoming more important as time goes on. Test and inspection systems from Kistler play a critical part in product quality as well as cost and resource efficiency, paving the way towards a zero-defect culture. As clear evidence of its enormous potential in this field, the Kistler Group will be represented with two stands at this trade show. Customers and interested visitors can witness demonstrations of ways to optimize their production processes so as to secure competitive edge.



The entire concept for Vester Elektronik GmbH's modular test cells is geared to modern manufacturing requirements. These test cells can be flexibly adapted to different parts, and they ensure high throughput rates, safety and reliability in the testing and sorting functions – with processing speeds that are often impressive.

Automated testing for punched, bent and turned parts
Vester Elektronik GmbH, which has recently joined the Kistler Group, will have a separate stand (hall 6, stand 413) featuring three automatic testing and sorting machines for use in punching and forming processes and also for testing individual series parts.

High-performance image processing systems enable users to perform fully automated dimensional and surface tests with gaging and hardness tests as additional options. The digital camera technology deployed for this purpose ensures 100% testing of mass-produced parts with very high throughput rates. Vester will also showcase the Smart Ray 3D laser triangulation sensor used in the testing process for an automated glass plate plant. This innovation makes it possible to measure height profiles as well as geometric and positional tolerances on the test object (such as flatness) that could not be visualized until now.

Frank Kirgis, Head of Division Industrial Process Control (IPC) at Kistler, notes: "Thanks to Vester, industrial image processing has now been added to the Kistler Group's wide-ranging stock of know-how. We are taking advantage of this opportunity to set up a Vision Center in Karlsruhe that will continue developing the related technologies."



INSPECTpro, the portable measuring instrument from Schatz, opens up new possibilities for random sample testing during assembly – in terms of hardware as well as software.

Universal fastener inspection – on the spot
Kistler's mobile inspection systems fulfill the requirements for efficient, standard-compliant quality assurance of threaded joints as well as fastening tools and systems. INSPECTpro, the portable measurement and evaluation instrument, offers a convenient way to test torque and rotation angle on threaded joints. This system provides graphic analyses of assembly processes to ensure that fastener assemblies meet optimum quality standards. Customers always need testing to be faster and more effective, so new custom software modules are constantly being developed to ensure easier handling and more transparent test processes.

combiTEST is a mobile inspection system that features dual capabilities: it combines calibration of manual torque wrenches with testing of automated fastening systems. The benefits: all the tools on an assembly line can be tested directly in situ – so their process capability is guaranteed.



For the first time, the combiTEST mobile test center from Schatz enables accurate, on-the-spot testing of all tools used in assembly, in compliance with the standards.

Integrated process monitoring generates added value
Thanks to their rugged design, piezoelectric sensors from Kistler keep precise track of quasi-static and highly dynamic force processes, even when production conditions are difficult. They offer many advantages over other technologies: proportionality, low measuring deflections and long service lifetimes. Another plus: they can also measure very small forces. At the Control trade show, Kistler will present a comprehensive portfolio of sensors including miniaturized versions that can be used when installation space is confined.

Last but not least, a groundbreaking innovation will be unveiled in Stuttgart: The world's first digital charge amplifier makes it possible to connect any desired piezoelectric sensors to the control directly via Ethernet (using Profinet, EtherCAT or Ethernet-IP). With analog disturbance variables excluded, users benefit from enhanced data consistency and transparency – in line with the requirements for Industry 4.0. As well as these advantages, the digital charge amplifier offers numerous measuring functions on four individually controllable channels. With up to 10,000 bus cycles per second and 50,000 measured values per channel and second, this innovation is the ideal choice for high-precision, time-critical control applications.



Kistler's digital industrial charge amplifier (Type 5074A) is the world's only amplifier for quasi-static measurement processes with piezoelectric sensors on real time-capable industrial Ethernet. It allows integration of any desired sensors with charge signals, and settings on the measurement amplifier can be made directly via the machine control.

Experience a vast range of testing technology in action!
Experience the wide-ranging quality assurance solutions offered by the Kistler Group at two stands in Stuttgart from 24 to 27 April 2018: Vester Elektronik GmbH – A Kistler Group Company (hall 6, stand 413); and the Kistler Group (hall 7, stand 313).


About the Kistler Group
Kistler is the global leader in dynamic measurement technology for measuring pressure, force, torque and acceleration. Cutting-edge technologies provide the basis for Kistler's modular solutions.
Customers in industry and science benefit from Kistler's experience as a development partner, enabling them to optimize their products and processes so as to secure a sustainable competitive edge. The owner-managed Swiss company's unique sensor technology plays a key role in the evolution of automobile development and industrial automation, as well as in numerous emerging sectors. With a broad knowledge of applications and an absolute commitment to quality, Kistler is making an important contribution to the further development of current megatrends. This includes topics such as electrified drive technology, automated and connected driving, emission reduction and Industry 4.0.
Some 1860 employees at 61 locations worldwide are dedicated to developing new solutions and offer customized service for individual applications. Since its founding in 1959, the Kistler Group has grown along with its customers, generating sales of CHF 422 million in 2017. Approximately 8% of this went back into research and technology - and thus into achieving better results for all our customers.



For more information, please contact :-

Kistler Instruments Ltd.
13 Murrell Green Business Park, London Road, Hook RG27 9GR
Tel: +44 (0)1256 741550
Fax: +44 (0)1256 741551
Email:
sales.uk@Kistler.com
Website: http://www.kistler.com

March 2018
