PCB Piezotronics - PRODUCT NEWS







New Ground-Isolated High Temperature Mini Triaxial ICP® Accelerometer
reduces electrical noise when testing in tight spaces

The new Model HTJ356B01 accelerometer from PCB® is suited for applications that demand ground isolation to reduce electrical noise and ground loops in higher temperature environments.

This innovative design achieves ground isolation by attaching the accelerometer to a three-sided titanium cup that contains an insulating glass filled epoxy. It has ICP® operation up to from -54 to 180°C.

The sensing elements provide a 5mV/g output over a 2 to 8K Hz frequency range and are hermetically sealed in a rugged titanium housing. With an overall cube size of just 7.1 mm and weight of 1 gram, it is ideal for testing in space restricted test locations. Typical applications include ESS and NVH testing in high temperature environments.


October 2017
