MSR Data Loggers on the way to the International Space Station ISS

For the fourth consecutive time, the miniature data logging devices of the Swiss electronics company MSR Electronics GmbH are accompanying the flights of the unmanned spacecraft 'Cygnus' to the International Space Station ISS to take transport measurements.

"We are getting truly spectacular data from these tiny data loggers", says Michael Bain, ISS Cargo Integration and Operations Services Manager of the Orbital Sciences Corporation. NASA, the National Aeronautics and Space Administration of the United States of America, contracts with Orbital Sciences Corporation for commercial cargo delivery to the International Space Station.

Precise monitoring of the cargo compartment
The MSR data loggers are being used in order to record shock and vibrations on the transport route of the supply transporter Cygnus to the ISS. According to Bain, cargo to the ISS includes consumables (food, clothing, science support, medical supplies, space operations support, periodic maintenance items, etc.), as well as spare parts, crew support, and science facilities. Some of the cargo is sensitive to the loads imparted during transportation, especially during launch where structural loads and vibrations can be significant.

The highly sensitive 3-axis-acceleration sensors of the MSR data loggers measure these strains, so called G forces, during the entire space flight until the transporter docks with the ISS, and record them in their internal memory. Michael Bain states: "We are able to track virtually every physical event that occurs on the spacecraft from roll-out to the launch pad, to rocket rotation to the vertical, to ignition, launch, main engine cut-off, stage separation, upper stage ignition and burn-out, fairing separation, ... even the movement of the spacecraft while attached to the space station arm."

On orbit, the MSR data loggers are retrieved from the module by the ISS crew as cargo is unloaded. The data files of the loggers are down-loaded to a Personal Computer onboard and then transmitted to the ground. According to Bain, Orbital takes the data, compares it against models and mission specific predictions and then submits an analysis of the loads seen by the cargo during the cargo delivery mission to NASA as proof that the systems operated as advertised.

Strict selection procedure
According to Wendelin Egli, CEO of MSR Electronics GmbH, Orbital selected the MSR165 data loggers partly because their sensors can autonomously perform precise measurements for long periods and with high measuring rates. "Another prerequisite for the space flight was that the loggers had a very low weight, small format and very high memory capacity - conditions which the MSR165 ideally fulfils". Batteries used in the MSR data loggers are individually tested and numbered at NASA's battery test facility at Johnson Space Centre in Houston, Texas. Tested batteries are shipped to MSR Electronics GmbH in Seuzach near Zurich and installed during initial production.

Each unit delivered from MSR Electronics GmbH to Orbital is serialized and certified to contain a NASA-tested battery. Each MSR data logger is then checked out and activated at Orbital Sciences Corporation in Dulles, Virginia, and later transported by plane or by car to the launch site, Wallops Flight Facility on Wallops Island, along the cost of Virginia. Once activated and prepared, they are installed in predetermined locations at the cargo compartment.

MSR's data loggers have meanwhile been used for Orbital four times: Test mission in September 2013, Orb-1 in January 2014, Orb-2 July 2014 and now Orb-3 (October 20, 2014).

About MSR Electronics GmbH
MSR Electronics GmbH, based in Seuzach, Switzerland, was established in 2006 following a management buyout of prospective concepts ag (Zurich, Switzerland). MSR Electronics GmbH took over and broadened all activities of the MSR department (MSR = Modular Signal Recorder) including development, production and marketing, together with sales and support for the MSR products.
The firm's core competencies lie in the development and sale of standard and application-specific dataloggers for a broad range of uses. MSR Electronics' customers include well known firms such as Alstom, BMW, Carl Zeiss, Decathlon, EMPA, Fein, Festo, Novartis, Oerlikon Balzers, Osram, Robert Bosch, Rega (the Swiss air rescue service), Siemens, W.L. Gore & Associates and many more.
For more information, please contact:-

MSR Electronics GmbH
Wendelin Egli, Managing Director
Mettlenstrasse 6
CH-8472 Seuzach, Switzerland
Tel. +41 52 316 25 55
Fax +41 52 316 35 21

October 2014
