iC-Haus GmbH - PRODUCT NEWS
Live webinar
Performance Booster for Sin/Cos Angular and Linear Position Sensors
iC-Haus warmly invites you to the next installment of its popular webinar series, presenting the new mixed-signal circuit iC-NQE, an innovative solution for boosting the performance of sin/cos angle and linear position sensors. The webinar will take place on May 20, 2025 at 9:30 a.m. Speaker Joachim Quasdorf will provide exciting insights into the technology, functions and application areas of the new IC. Participation is free of charge.
Robust magnetic angular and linear position sensors typically use coarse scale gratings to achieve a comfortable reading distance. The resolution on the input side is low, and the signal processing and conversion requirements to obtain an accurate position are correspondingly high. Furthermore, linear applications tend to require higher movement speeds without compromising on standstill accuracy: a stable position with low jitter is an absolute must. The new iC-NQE signal converter meets these demanding
requirements and offers further advantages in the application.
The new iC-NQE is a highly integrated mixed-signal circuit for magnetic XMR, inductive, and optical position sensors with real-time 16-bit sine-to-digital conversion and precise analog and digital signal processing. Additional system functions such as status monitoring and the necessary cable drivers for incremental quadrature and absolute BiSS data output are integrated, saving costs and valuable board space in the sensor read head. Applications include absolute and incremental position encoders, drive speed and torque control, brushless motor commutation, robots, AGVs, and many more. On the control side, e.g. on IPC interface cards, in drives or PLCs, iC-NQE could also be used as a 32-bit counter module for input signals of up to 500 kHz.
iC-NQE is a perfect match for the inductive sensor front-end iC-GI22, which will be
demonstrated in the webinar.
This is how you benefit from this iC-Haus live webinar:
• Understand the fundamentals of sin/cos interpolation and signal error correction
• Learn how to apply the iC-NQE sensor converter
• See a live demonstration on how iC-NQE compensates signal errors and distortion
Registration for the free webinar is now open:
Performance Booster for Sin/Cos Angular and Linear Position Sensors
Further information: https://www.ichaus.de
Related products:
iC-SM2L, iC-SM5L, iC-GI22, iC-NQI, iC-NQC, iC-PI
iC-Haus exhibits at:
Sensor + Test 2025 Nuremberg
6-8 May, 2025 hall 1 booth 1-534
automatica 2025
24-27 June, 2025 Munich hall B5 booth 408
Laser World of Photonics 2025
24-27 June, 2025 Nuremberg hall B2 booth 316
Introducing iC-Haus
iC-Haus GmbH is a leading, independent German manufacturer of standard iCs (ASSP) and customized ASiC semiconductor solutions with worldwide representation. The company has been active in the design, production, and sales of application-specific iCs for industrial, automotive, and medical applications for over 40 years.
The iC-Haus cell libraries in CMOS, bipolar, and BCD technologies are specifically suited to realize the design of sensor, laser/opto, and actuator ASiCs, among others. The iCs are assembled in standard plastic packages or using the iC-Haus chip-on-board technology to manufacture complete microsystems, multichip modules, and optoBGA/QFN in conjunction with sensors.
Further information is available at https://www.ichaus.de
For any queries, please contact:
Joachim Quasdorf
iC-Haus GmbH, Am Kuemmerling 18, 55294 Bodenheim, Deutschland
Tel.: +49 6135 / 9292 306
joachim.quasdorf@ichaus.de
Introducing iC-Haus
iC-Haus GmbH is a leading, independent German manufacturer of standard iCs (ASSP) and customized ASiC semiconductor solutions with worldwide representation. The company has been active in the design, production, and sales of application-specific iCs for industrial, automotive, and medical applications for 40 years.
The iC-Haus cell libraries in CMOS, bipolar, and BCD technologies are specifically suited to realize the design of sensor, laser/opto, and actuator ASiCs, among others. The iCs are assembled in standard plastic packages or using the iC-Haus chip-on-board technology to manufacture complete microsystems, multichip modules, and optoBGA/QFN in conjunction with sensors.
Further information is available at http://www.ichaus.de
For any queries, please contact:
Joachim Quasdorf
iC-Haus GmbH, Am Kuemmerling 18, 55294 Bodenheim, Deutschland
Tel.: +49 6135 / 9292 306
joachim.quasdorf@ichaus.deSilvan Ettle
iC-Haus GmbH, Am Kuemmerling 18, 55294 Bodenheim, Deutschland
Tel.: +49 6135 / 9292 327
For more information, please contact:
iC-Haus GmbH
Am Kuemmerling 18, 55294 Bodenheim, Germany
Tel. +49 6135/9292-300
Fax +49 6135/9292-192
Email: info@ichaus.de
Web: www.ichaus.deApril 2025
